TANDEM AXLE HOPPER
General Information
With over 50 years of trailer manufacturing experience, only the best materials available go into the manufacturing of each Cornhusker 800 Trailer. Our Cornhusker 800 Hopper Trailer is a durable, light-weight, bulk commodity hopper trailer that will provide years of dependable service, larger profits, and higher resale value. The Cornhusker 800 Trailer is designed using high-test aluminum alloys throughout the construction of the trailer.
Using these aluminum alloys and our unique design creates one of the lightest weight hopper trailers in the industry. Each unit is equipped with full air ride and with standard options has an estimated weight of less than 8000 lbs.
Detailed Specs
| Lengths Range from 38′ to 45′ (Inquire if Custom Size Required) |
| Side Height Ranges from 67.5″ to 103.5″ (In 4″ Increments) |
| 96″ or 102″ Trailer Width |
| White, Black, or Gray Skins |
| (1/2/3) Rows of (3/5/7/9/13) Grote LED Lights (2 1/2″ or 3/4″ Button Lights) |
| Aluminum Kingpin Section |
| Jost Alumilight Landing Gear |
| Fabbed 30″ X 40″ Aluminum Roller Trap with Aluminum Door |
| 2-Speed Manual Gearbox |
| Aluminum Subframe Section |
| Ridewell 266 Air Ride Suspension with Drum or Disc Brakes |
| Aluminum Wheels fitted with Most Major Tire Brands |
| Shur-Co Manual Tarp System with 18 oz. Diamond Core Tarp |
| White, Black, or Gray Smooth Side Skins (Covers Stake Sides) |
| Smooth Stainless Steel Skins (Partial or Full Coverage for Front/Rear and/or both) |
| Additional Lighting Customization and Clear Lens LEDs |
| Kingpin Depth Settings 18″ — 30″ in 2″ increments |
| Additional Trap Door Sizes 24″ x 40″ / 30″ X 52″ / 36″ X 40″ |
| Shur-Co Electric Pro Trap or Thunder Hydraulic Powered Traps |
| Knock Rails |
| 1.25″ or 2″ Vibrators with Luber Regulator |
| Front or Rear Lift Axle |
| Semi-Fluid Grease Hubs |
| P.S.I. Tire Auto Inflation System |
| Shur-Co 4500HD or Thunder 7000 Powered Tarp Systems |
| Multiple Tarp Colors, 22 oz. Material, Reinforced Bows, and Ridge Pole Options |
| Shur-Co Enclosed Tarp End Caps |
| Rear Tow Loops |
| Personalized Rear Skirt Sign (Lighted or Reflective Wording / Logo) |
